Actual KV here measured in our shop is 1207. Motors like this mostly commonly used 3S for sport ship range where moderate to high pitch speeds are required. A motor like this is perfect for many aircraft and commonly used on models from 16-32 oz. A good motor on our Stick 400 and other similar kits.
Specifications As Per MFG:
Weight
Size D x L
Amps
Shaft
Max Motor RPM
KV
Resistance
No Load Current
55g/1.94oz.
27.7mm (1.102") x 29.5mm (1.091")
19.5A (275 watts)
3.17mm (1/8") x 44.9mm OAL
Non-Pub
Actual 1207 (1300 Claimed)
Non-Pub
Non-Pub
Setup and Performance Chart
# Cells
Prop
Amps
Watts In
RPM
Thrust oz.
Pitch Speed MPH
2
GWS 9x5HD
1.8
89
7,800
18
35
2
APC 9 x 7E
14.9
112
7,470
20
48
2
APC 10 x 6E
17.6
132
7,180
24
39
3
APC 7 x 6E
12.5
141
12,140
21
67
3
APC 8 x 4E
13.6
153
12,010
25
43
3
APC 8 x 6E
18.3
206
11,470
30
63
3
APC 9 x 4.5E
20.6
232
11,200
36
46
4
APC 6 x 5.5E
11.7
176
16,650
22
84
4
APC 7 x 4E
14.5
218
16,300
31
59
4
APC 7 x 6E
19.8
297
15,640
35
86
5
APC 6 x 4E
13
244
20,900
31
75
5
APC 6 x 5.5E
16.8
315
20,390
33
102
5
APC 7 x 4E
20.8
390
19860
47
71
Estimates based on manufacturers provided constants using E-Calc. High Quality 2200mah used as trial cell in calculations. Actual performance may vary depending on components used, accuracy of data as provided by manufacturer, quality of ESC, weather and many other variables.
 "MTO2830-1300")
