Savox SW-0250MG Waterproof, High Torque, Digital Mini ServoThe SW-0250MG is a waterproof, high torque, digital mini servo that performs! An excellent replacement for the standard servo found in Traxxas 1/16 scale vehicles.
Features: - Strong metal gear train for added durability.
- Waterproof case design.
- Ideal for cars and boats subject to water or snow.
- Ideal for Traxxas 1/16 vehicles.
Specifications: - Torque @4.8v - 3.5kg/48.6oz-in
- Torque @6v -5.0kg/69.4oz-in
- Speed @4.8v - 0.14 sec/60 deg
- Speed @6v - 0.11 sec/60 deg
- Dimensions L x W x H (mm): 29.5 x 14.0 x 32.5
- Weight: 25.0g
- Operating Temperature: 14° - 122°F (-10° - 50°C)
- Running Current (no load): 80mA @4.8V, 100mA @6.0V
- Stall Current (at locked): 1000mA @4.8V, 1250mA @6.0V
- Idle Current: 5mA @4.8V, 5mA @6.0V
- Wire Length: 200 +- 5mm
- Output Gear Spline: 25 Tooth
- Bearings: 1BB
- Operating Travel: 100° (1000 -> 2000 μ second)
- Neutral Position: 1500 μ second
- Pulse Width Range: 800 -> 2200 u second
- Maximum Travel: Appx 130° (900 -> 2100 μ second)
- Refresh Rate: 240 Hz
- Motor Type: Brushed
SOLD OUT, See SAVSW-0250MGP for replacement
SKU Number: SAVSW-0250MG
|
