Actual KV here measured in our shop is 1207. Motors like this mostly commonly used 3S for sport ship range where moderate to high pitch speeds are required. A motor like this is perfect for many aircraft and commonly used on models from 16-32 oz. A good motor on our Stick 400 and other similar kits.
Specifications As Per MFG:
Weight
Size D x L
Amps
Shaft
Max Motor RPM
KV
Resistance
No Load Current
73g/2.72oz.
27.7mm (1.102") x 35.86mm (1.412")
25.4A (368 watt)
4mm (.159") x 44.9mm OAL
Non-Pub
Actual 1478
Non-Pub
Non-Pub
Setup and Performance Chart
# Cells
Prop
Amps
Watts Input
Lost Watts (Heat)
% Motor Efficiency
RPM
Static Thrust Ounces
Pitch Speed MPH
2
9x7
23.5
176
40
75%
8,150
24
54
2
10x6
27.1
203
50
73%
7,670
28
44
3
7x6
21.4
241
39
82%
13,810
27
78
3
8x4
23.3
262
44
82%
13,540
31
51
3
8x6
29.8
335
63
79%
12,610
37
72
4
6x5.5
20.7
311
43
85%
19,300
30
101
4
7x4
25.5
383
55
84%
18,650
42
70
4
7x5
29.5
443
67
83%
17,940
45
85
5
6x4
23.5
441
55
87%
24,230
43
92
Estimates based on manufacturers provided constants using E-Calc. High Quality 2200mah used as trial cell in calculations. Actual performance may vary depending on components used, accuracy of data as provided by manufacturer, quality of ESC, weather and many other variables.
