  1. Whats New >
  2. Orbit Specialty Items

Orbit Chargers and Charger Accessories are found by looking under "Chargers, Cords & Testers" at left, look for sub catagory "Orbit.....".

Sort By:
evoJet Orbit Pro Premium R/C Pneumatic Single Action Landing Gear Valve - Product Image
Click for larger image

evoJet Orbit Pro Premium R/C Pneumatic Single Action Landing Gear Valve

The PRO pneumatic evoJet Orbit valves are based on first-class miniature valves with Viton seals. These valves are equipped with entirely new digital micro controllers, making their handling even more convenient:

* Freely programmable switching points for compatibility with all R/C equipment
* Switch mode(gear) or Pulse width mode(brakes) selectable
* Completely EMC compliant (electromagnetic compatibility)

The valve is simply connected to a receiver output just like you would connect a servo, or e.g. combined with the elevator servo as a braking valve. This allows precise and easy programming of the switching points with the help of a small push-button on the valve. A red LED informs you about the current switching state.

This one-way version is suitable for landing gears and flaps with built-in spring or as a proportional braking valve.

* Weight: 21 g
* Power: 4.8 - 6 V / 100 mA
* Connector selection:
A3: barbed pushover for 3mm+Robart
A4: barbed pushover for 4mm tubing
B: QS-3 straight for 3mm tubing
C: QS-3 90? turnable for 3mm tubing
* Operating pressure: max. 10 bar
* Nominal flow rate: 12 l/min
* Dimensions (W x H x D): 16 x 28 x 30 mm

SKU Number: EVO0980P

Price: $83.00
Quantity:

evoJet Orbit PRO R/C Pneumatic Dual Action Landing Gear Valve - Product Image
Click for larger image

evoJet Orbit PRO R/C Pneumatic Dual Action Landing Gear Valve

The evoJet Orbit PRO Dual-Action-Valve is designed for compressed air cylinders without a return spring (e.g. Robart, BVM), where both the extension and retraction of the landing gear or flaps are powered by compressed air. The PRO-Premium pneumatic valves are based on first-class miniature valves with Viton seals. These valves are equipped with new digital microcontrollers, making their handling even more convenient:

Freely programmable switching points for compatibility with all R/C receivers.
No more drifting of the switching points.
Completely EMC compliant (electromagnetic compatibility)

The valve is simply connected to a receiver- or controller-output just like you would connect a servo. This allows precise and easy pro-gramming of the switching points with the help of a small push-button on the valve. Two LED's informs you about the current switching state.

This dual version is suitable for dual action cylinders.
Press-button for manual operation
Air pressure up to 10 bar / 145 psi

Fitting selection:
A3: barbed pushover for 3mm+Robart
A4: barbed pushover for 4mm tubing
B: QS-3 for 3mm tubing
C: QS-4 for 4mm tubing

High flow rate of 12 l/min Power: 4.8 - 6 V / 100 mA Weight: 55 g incl. cable W x H x D: 40 x 32 x 30 mm
SKU Number: EVO0981P

Price: $122.00
Type of Fittings
Quantity:

evoJet Orbit R/C Pneumatic 3mm Festo tube fitting into 5mm valve - Product Image
Click for larger image

evoJet Orbit R/C Pneumatic 3mm Festo tube fitting into 5mm valve

Festo adapter QSM. 3mm-3mm tube size. Screws into evoJet Orbit pneumatic valves with 5mm threads (Fits valves 0981 and 0982). Use for retractable landing gear or brake systems. Pressure range: =12 to 110 psi.
SKU Number: EVO0867B
Price: $6.00
Quantity:

evoJet Orbit R/C Pneumatic 4mm Festo tube fitting into 5mm valve - Product Image
Click for larger image

evoJet Orbit R/C Pneumatic 4mm Festo tube fitting into 5mm valve

Festo adapter QSM. 4mm tube size. Screws into evoJet Orbit pneumatic valves with 5mm threads (Fits valves 0981 and 0982). Use for retractable landing gear or brake systems. Pressure range: =12 to 110 psi.
SKU Number: EVO0867C
Price: $6.00
Quantity:

evoJet Orbit Pneumatic 3mm Straight Pushover Fitting for 5mm Valve - Product Image
Click for larger image

evoJet Orbit Pneumatic 3mm Straight Pushover Fitting for 5mm Valve

3mm tube size. Screws into evoJet Orbit pneumatic valves threaded for 5mm fittings (0981, 0982 valves). Use for retractable landing gear and brake system controls. Pressure range: =12 to 110 psi.



Sorry, sold out, no longer available from manufacturer


SKU Number: EVO0869A3

evoJet Orbit R/C Pneumatic 4mm straight Tube Pushover Fitting for 3mm Valve - Product Image
Click for larger image

evoJet Orbit R/C Pneumatic 4mm straight Tube Pushover Fitting for 3mm Valve

4mm tube size. Screws into evoJet Orbit pneumatic valves with 3mm threads. Use for retractable landing gear or brake systems.
Pressure range: =12 to 110 psi.

SKU Number: EVO0869A4
Price: $6.00
Quantity:

evoJet Orbit Pneumatic 3mm Robart Elbow fitting Nipple/Pushover A3.90 - Product Image
Click for larger image

evoJet Orbit Pneumatic 3mm Robart Elbow fitting Nipple/Pushover A3.90

3mm tube size. Provides 90 degree angle. Screws into evoJet Orbit pneumatic valves threaded for 5mm fittings (Fits valves 0981 and 0982). Use for retractable landing gear or brake system controls. Pressure range: =12 to 110 psi.



Sorry! Temporarily out of stock.


SKU Number: EVO0869A3.90

evoJet Orbit R/C Pneumatic 3mm Festo tube fitting into 3mm valve - Product Image
Click for larger image

evoJet Orbit R/C Pneumatic 3mm Festo tube fitting into 3mm valve

Festo adapter QSM. 3mm-3mm tube size. Screws into evoJet Orbit pneumatic valves with 3mm threads (Fits valves 0980). Use for retractable landing gear or brake systems. Pressure range: =12 to 110 psi.
SKU Number: EVO0867C
Price: $6.00
Quantity:
