We packed as much brute power and intelligence into this tiny layout as we possibly could and came up with a 15 amp* controller with ability to sustain an 8 amp BEC! Talon 15 measures just 1.1" long and is under 0.6" wide! At nearly the size of a quarter, this ESC supports an outlandish 8 amp** peak BEC with output voltage of 5.5 VDC. Applications range from foamies to micro and sub-micro helis running up to 4S and pulling 15 amps. As with any Castle ESC, the Talon 15 offers Castle's industry-leading functions, not to mention easy programming using the Castle Link USB adapter (coupon for free Castle Link included), or the Castle Field Link Portable Programmer (sold separately).

Notes from Dave: This is a world beater ESC. Now we can run high voltages in our smaller models with a small tight ESC from a quality manufacturer. I'm very excited to put one of these in my 5S, 16 ounce Stick 400. Sweet!

Input Voltage: 2-4 Lipo
Max Continuous Amperage: 15*
BEC Voltage: 5.5v
BEC Amperage: 3 Continuous, 8 Surge**
Switching Rate 7,000 Hz
Resistance 0.0065 Ohms
Brake yes, programmable
Reversible yes - change any two wires
Size .058 x 1.1 x 0.32 in.
Weight (w/wires) 0.25 oz. (7.2g)
Universal connector

*RC HOBBY APPLICATION RATING: 15 amps for the duration of a single 4,000 mAh battery pack with the ESC in contact with a 5 mph airflow of 25C (77F) or cooler air. Controller temperature must never exceed 100C (212F). Exceeding current or temperature ratings may damage components and may shorten the life of the ESC. Always verify system current draw at full-throttle. Decrease load or increase airflow to decrease the ESC's operating temperature.

**Peak indicates amperage sustainable for most servos' current draw transients. Always confirm servo current draw before the first flight of the model.

Castle Creations Warranty Info.

Talon HV 120 is the first high voltage controller to come out of the Castle factory with a built-in BEC. This powerhouse features a 20A peak BEC with selectable 6v or 8v output voltage. With a voltage input range from 3S to 12S LiPo, and a 120A continuous amperage capability, it's capable of up to 6000W of continuous power for a wide variety of heli and fixed wing applications. The sleek aluminum case keeps the ESC cool during high power demand situations. For set-ups with limited airflow, such as under canopies or in a fuselage, there is an optional 40mm fan (sold separately; operates at 4.8 - 7.4 volts). Talon HV 120 has access to Castle's industry leading software functions, and USB programming capability via Castle Link USB Adapter. *Remove BEC Power wire from receiver before connecting to Castle Link.

The Talon ESCs are programmed to sound a number of tunes and codes using the motor as well as flashing LED patterns to alert users to certain conditions regarding their power system, such as over temperature, excessive load and locked head speed.

Telemetry Capable

Telemetry has the potential not only to improve the safety of our models by monitoring battery voltages, ESC temperature, and other critical parameters, but it also creates other opportunities to get even more fun out of flying because you've essentially reduced the risks of "unknown" inevitable crashes. Think of the benefits to be had from alarms that will sound to warn you when there's interference about or if your receiver battery is running unexpectedly low. Requires purchase of Castle Telemetry Link for S.BUS2 (Item # 010-0152-00) and compatible Futaba Radio or Castle Telemetry Link for X-BUS (Item# 010-0148-00) and a compatible Spektrum Radio.

Warranty

Coupled with our unparalleled 1-year warranty and world-famous technical support, Castle provides confidence and peace of mind that your Talon 120 HV is a smart investment. In this day of "throw-away" electronics, put your investment in a trusted name with a proven track record of support and service.

Firmware Upgrade

Users will receive free access to all firmware updates, including added features sets using the Castle Link USB Programming Kit

Castle Link Compatible

With the Castle Link USB Programming Kit you can use your Windows(TM) PC to easily program your controller. Castle Link includes all code for all Castle Link compatible hobby products in one convenient download. Note: Castle Link software requires a Castle Link USB Adapter and a computer that is running Windows. Castle Link is compatible with Windows Vista, Windows 7, Windows 8 and Windows 10.Macintosh users may take advantage of software such as Parallels Desktop, VMware Fusion, or Apple's Boot Camp along with Windows Vista, Windows 7, Windows 8, or Windows10 to run the Castle Link software, provided the Macintosh has an Intel processor. Macintosh installation is not supported by Castle Creations.

Additional Castle Link benefits include:

Access expanded programming and parameters for Castle controllers (see overview below)

Access to all firmware updates, including added features sets released from Castle Engineering, at no charge.

Intuitive Demo Mode capability

Ability to default ESC to factory settings

Ability to save setup profiles for later use

Ability to download and view data logs (on applicable controllers)

Input Voltage Range: MIN: 3S LiPo

MAX: 12S LiPo

Max Continuous Amperage at full throttle: 120 amps*

Max Voltage: 50.4V

BEC Voltage: User selectable choice of 6 or 8 volts output

BEC Output: 20 amp peak**, 10 amp continuous (always check servo draw prior to first flight)

Size: Width: 2.01" (51.1mm)

Length: 4.15" (105.4mm)

Depth: 0.80" (20.4mm)

Weight (w/wires): 6.56 oz. (186g)

Connectors: Built-in 5.5mm female bullets, matching 5.5mm male bullets included, battery connector sold separately.

Items Needed for Operation: Battery connectors (sold separately)

Product Use Statements: Remove BEC Power wire from receiver before connecting to Castle Link.

Note: If using motors with stiff wires it is recommended to use extensions with flexible silicone wires to prevent stress to the female bullets on the ESC.

Application Guidelines: Not intended for use with backup guards. If running an external BEC you must disconnect the middle wire (red) on the throttle lead and do not plug in the two-wire BEC lead.

Programmability: Fully programmable Castle feature set using Castle Link USB adapter (coupon for free Castle Link adapter included in package) and freely downloadable Castle Link Windows software.

Telemetry Link Capable: Yes, except Battery Current

Tech Notes: N/A

Resources

Talon HV User Guide Talon HV BEC Wire Warning

*RC HOBBY APPLICATION RATING: 120 amps for the duration of a single 10,000 mAh battery pack with the ESC in contact with a 5 mph airflow of 25?C (77?F) or cooler air. Controller temperature must never exceed 100?C (212?F). Exceeding current or temperature ratings may damage components and may shorten the life of the ESC. Always verify system current draw at full-throttle. Decrease load or increase airflow to decrease the ESC's operating temperature.

**Peak indicates amperage sustainable for 0.5 seconds - long enough for most servos' current draw transients. Always confirm servo current draw before the first flight of the model.

Castle Creations, Inc. warrants this product to be free from manufacturing defects for a period of one year from date of purchase.

This is a high power product with the potential to be very dangerous. Please read the safety information before use. This product may contain chemicals known to the State of California to cause cancer and or birth defects or other reproductive harm.

U.S. Patent # 7400103, 7492122, 7579796, 7740516, 8287328, 8678875, and 8905814 B2 - Other patents pending

The Talon 60 is well suited for SMALL SCALE OR AEROBATIC HELIS ranging from 360-450 size requiring up to 1400 watts on 6S. This ESC offers Castle's industry-leading helicopter functions, such as the remarkable direct entry governor mode. Simply type in the desired RPM using a Castle Link USB adapter (redeemable coupon enclosed with purchase) and the free Castle Link Programming Suite running on a Windows (TM) PC.

The compact layout and slim profile of the Talon 60 is also perfect for SCALE, SPORT and AEROBATIC PLANES in the .32 - .60 range requiring up to 1400 watts on 6S. Mounting the Talon 60 is simple and stress-free in any setup.

The Talon series ESCs are known for sporting heavy-duty BEC's designed for today's servos. The Talon 60 is no exception. With its 20 AMP PEAK POWER and 8 AMPS OF CONTINUOUS POWER, it will keep even the most draining servos at ease.

CASTLE-LINK(TM)

For nearly 20 years Castle engineers have been setting the bar for industry leading software functionality. The Castle Link Programming Suite is the ticket to creating the perfect setup. Gaining access to the host of tuning parameters, including free firmware updates and added feature sets, requires only the Castle Link USB adapter (redeemable coupon enclosed with purchase) and the free Castle Link software on your Windows (TM) PC. Users can then fine tune many variables to enhance their level of expertise.

Power System Alerts

The Talon ESCs are programmed to sound a number of tunes and codes using the motor as well as flashing LED patterns to alert users to certain conditions regarding their power system, such as over temperature, excessive load and locked head speed.

Telemetry Capable

Telemetry has the potential not only to improve the safety of our models by monitoring battery voltages, ESC temperature, and other critical parameters, but it also creates other opportunities to get even more fun out of flying because you've essentially reduced the risks of "unknown" inevitable crashes. Think of the benefits to be had from alarms that will sound to warn you when there's interference about or if your receiver battery is running unexpectedly low. Requires purchase of Castle Telemetry Link for S.BUS2 (Item # 010-0152-00) and compatible Futaba Radio or Castle Telemetry Link for X-BUS (Item# 010-0148-00) and a compatible Spektrum Radio.

The TALON 60 is PROUDLY DESIGNED, MANUFACTURED AND SUPPORTED IN OLATHE, KANSAS, and is backed by Castle Creations' 1-year warranty and unparalleled 'make-it-right' customer support.

Technical Specs

Input Voltage Range: MIN: 2S LiPo

MAX: 6S LiPo

Max Continuous Amperage at full throttle: 60 amps*

Max Voltage: 25.2V

BEC Voltage: User selectable choice of 6 or 8 volt output (default is 6V).

BEC Output: 20 amp peak** , 8 amp continuous

Size: Width: 1.19" (30.2mm)

Length: 2.56" (65mm)

Depth: 0.41" (10.6mm)

Weight : 2.05 oz. (57 g) with wires

1.09 oz. (g) without wires

Connectors: N/A

Items Needed for Operation: Battery and Motor connectors sold separately.

Tools needed for installation: Soldering iron for attaching High Current bullet connectors to ESC, motor, and battery. (Deans Ultra Plugs, EC5 or Castle Polarized 4mm or 6.5mm)

Application Guidelines: SMALL SCALE OR AEROBATIC HELIS ranging from 360-450 size requiring up to 1400 watts on 6S and SCALE, SPORT and AEROBATIC PLANES in the .32 -. 60 range requiring up to 1400 watts on 6S.

Programmability: Fully programmable Castle feature set using Castle Link USB adapter (coupon for free Castle Link adapter included in package) and freely downloadable Castle Link Windows software. (A small subset of the settings available through Castle Link Windows software can be accessed via manual programming through the transmitter stick.)

Telemetry Link Capable: Yes

Tech Notes: N/A

TEMPORARILY OUT OF STOCK

This compact controller can keep it's cool even during the most extreme 3D maneuvers. Talon 25 is intended for use in most 400-size helicopter setups running up to 6S LiPo or your favorite 3D foamy that pulls up to 25 amps. Despite it's size, it boasts an impressive 8 amp peak/3 amp continuous BEC, keeping even the most draining servos at ease. Talon 25 also offers Castle's industry-leading helicopter functions, not to mention easy programming using the Castle Link USB adapter (coupon for free Castle Link included). Talon 25 tips the scales at a mere 18 grams!

Notes from Dave: This is a world beater ESC. Now we can run high voltages in our smaller models with a small tight ESC from a quality manufacturer. I'm very excited to put one of these in my 5S, 16 ounce Stick 400. Sweet!

Input Voltage: 2-6 Lipo
Max Continuous Amperage: 25*
BEC Voltage: 5.5v
BEC Amperage: 3 Continuous, 8 Surge**
Switching Rate 7,000 Hz
Resistance 0.0065 Ohms
Brake yes, programmable
Reversible yes - change any two wires
Size .072 x 1.72 x 0.32 in.
Weight (w/wires) 0.63 oz. (17.9g)
Universal connector

*RC HOBBY APPLICATION RATING: 25 amps for the duration of a single 4,000 mAh battery pack with the ESC in contact with a 5 mph airflow of 25C (77F) or cooler air. Controller temperature must never exceed 100C (212F). Exceeding current or temperature ratings may damage components and may shorten the life of the ESC. Always verify system current draw at full-throttle. Decrease load or increase airflow to decrease the ESC's operating temperature.

**Peak indicates amperage sustainable for most servos' current draw transients. Always confirm servo current draw before the first flight of the model.

Castle Creations Warranty Info.

This "mighty mini" can take on the most extreme maneuvers while keeping it's cool. Talon 35 is intended for use in 450 Heli setups running up to 6S or .10 to .20 fixed wing applications pulling up to 35 amps and boasts a 7 amp peak/5 amp continuous BEC, keeping even the most draining servos at ease. Talon 35 also offers Castle's industry-leading helicopter functions, not to mention easy programming using the Castle Link USB adapter (coupon included). The compact layout and thin profile make mounting Talon 35 simple and stress-free in any setup.

Input Voltage: 2-6 Lipo
Max Continuous Amperage: 35*
BEC Voltage: 5.5v
BEC Amperage: 5 Continuous, 7 Surge**
Switching Rate 7,000 Hz
Resistance 0.0065 Ohms
Brake yes, programmable
Reversible yes - change any two wires
Size .088 x 1.93 x 0.33 in.
Weight (w/wires) 0.98 oz. (27.8g)
Universal connector

*RC HOBBY APPLICATION RATING: 55 amps for the duration of a single 4,000 mAh battery pack with the ESC in contact with a 5 mph airflow of 25C (77F) or cooler air. Controller temperature must never exceed 100C (212F). Exceeding current or temperature ratings may damage components and may shorten the life of the ESC. Always verify system current draw at full-throttle. Decrease load or increase airflow to decrease the ESC's operating temperature.

**Peak indicates amperage sustainable for most servos' current draw transients. Always confirm servo current draw before the first flight of the model.

Castle Creations Warranty Info.

UPC code:819326010316

Designed for Helis
Talon 90 is ideal for helicopters drawing 2,000 watts on 6S. It's a great fit for extreme 500 and 550 class helis and sport (6S) 600 setups, and offers Castle's industry-leading helicopter functions, such as the unbelievable direct entry governor mode.

Great for Fixed Wing
Talon 90 is perfect for aerobats up to 10 pounds and scale ships up to 20 pounds.

Features:

Beefy 20 amp peak (9 amp continuous)
5.5mm horizontal motor connectors installed, battery connectors sold separate
Innovative case ensures cooling in even the toughest mounting locations
Programmable via Castle Link Adapter (coupon for free Castle Link Adapter included with purchase) and a Windows PC, a Castle Field Link (sold separately) or the Castle Link iOS App and a B-Link Bluetooth Adapter (sold separately).
Audible alerts for error conditions
Telemetry compatible with purchase of Castle Telemetry Link for S.BUS2 (Item # 010-0152-00) and compatible Futaba Radio or Castle Telemetry Link for X-BUS (Item# 010-0148-00) and a compatible Spektrum Radio.
Designed, manufactured, and supported from Olathe, KS USA

What's Included:

Talon 90
(3) 5.5mm male bullets
Talon User Guide
Talon Quick Reference Guide

Talon 90 delivers premium performance and features at an amazing price!

Cells w/ BEC 5-10
Cells w/o BEC 5-16
Continuous 10 Amps
Surge 15 Amps
Switching Rate 7,000 Hz
Resistance 0.013 Ohms
Brake yes, switchable on and off
Reversible yes - change any two wires or with programming
Size 1.08 x 0.91 x 0.16 in.
Weight (w/wires) 0.3 oz. (8.5g)
Universal connector

Castle Creations Warranty Info.

SKU Number: CCPHX10

Castle Creations Warranty Info.

DISCONTINUED BY CASTLE, WHILE SUPPLIES LAST

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect complement to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 80A model comes with a 5.5 volt switching BEC rated for 6 amps of current to handle the power needs of the larger digital servos.

Because of the wide range of different motor connectors used on this size speed controller, the Cobra 80A ESC comes without any bullet connectors already installed. The motor leads are pre-tinned and ready to solder on your favorite connectors. 4mm or larger bullet connectors are recommended for this size speed controller.

Cobra Speed Controller Features:

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 80 Amp ESC Specifications:

Weight (Without Connectors): 60.1 grams (2.12 oz)

Max Continuous Current: 80 Amps

Burst Current rating (15s): 100 Amps

Operating Voltage Range: 6 to 26 Volts

Number of Li-Po cells: 2 to 6 cells

Number of Ni-XX cells: 6 to 20 cells

Number of Li-Fe cells: 2 to 7 cells

Switching BEC Output: 6 amps @ 5.5 Volts

ESC Size (Inc. Caps, in mm): 72 x 33 x 14

ESC Size (Inc. Caps, in inches): 2.83 x 1.30 x 0.55

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Castle Creations Warranty Info.

SOLD OUT, MANUFACTURER BACKORDER, PENDING PRODUCTION

The Phoenix Edge series is intended for use in helicopters ranging from 450 to 800 size, and fixed wing aircraft up to 1.20 size and larger. As always, the Edge series of controllers offer industry-leading software functions, data logging, and USB programming capability via Castle Link USB adapter (free with included coupon).

Specifications Ice 60HV:
Dimensions:2.0" (50.8mm) x 2.8" (71.9mm) x 0.9" (23.2mm)
Max Input Voltage 3S to 12S Lipo, 9S A123, 22 cells Nicad or NiMH.
Max Continuous 60 Amps
Brake yes, on/off
Reversible yes - change any two wires
Low Voltage Cut-off, auto Lipo or NiMH/NiCd
PWM Switching Rate: 8,12 or 16 kHz Weight (w/wires) 3.9 oz. (110.2g)
BEC: Use External BEC
Universal RX Connector

Castle Creations Warranty Info.

The Phoenix Edge series is intended for use in helicopters ranging from 450 to 800 size, and fixed wing aircraft up to 1.20 size and larger. As always, the Edge series of controllers offer industry-leading software functions, data logging, and USB programming capability via Castle Link USB adapter (free with included coupon).

Specifications Ice 80HV:
Dimensions:2.0" (50.8mm) x 2.8" (71.9mm) x 0.9" (23.2mm)
Max Input Voltage 3S to 12S Lipo, 9S A123, 22 cells Nicad or NiMH.
Max Continuous 80 Amps
Brake yes, on/off
Reversible yes - change any two wires
Low Voltage Cut-off, auto Lipo or NiMH/NiCd
PWM Switching Rate: 8,12 or 16 kHz Weight (w/wires) 4.4 oz. (124.6g)
Universal RX Connector
BEC: Use external BEC

Castle Link Compatible

Castle Creations Warranty Info.

Set up of programmable options with point and click ease.
View your current Phoenix program settings.
Customize values for low-voltage cutoff, prop brake strength and governor mode gain.
Download new software updates via the internet as they become available.

NEW revised interface featuring:
All-in-one support for Phoenix, Mamba, Barracuda, Phoenix HV, and Thunderbird brushless controllers!
Now with saved settings files!
New "check for updates" feature!
Totally automatic install!
Expanded programming and parameters for all Castle car controllers
No complicated connections! It's as easy as:
1. Download the interface software from our Software area.
2. Plug the C-Link into the receiver lead on your Phoenix controller and attach the mini USB cable included in the kit.
3. Connect the USB cable to your PC.
The C-Link works with all Castle Creations brushless controllers (manufacturing date August 2003 or later, Marine versions not compatible).
Castle Creations Warranty Info.

Field Link allows you to modify the most commonly used settings in your Castle controller all at the touch of a single button. No computer needed (mostly). Simply connect the Field Link to the throttle lead of the controller and power the pair as described below. Click the button to scroll through and change the indicated settings. Can't get any easier! USB to computer link included.

Data points include: Battery Voltage, Battery Ripple, Battery Current, Controller Temperature, Motor RPM, Controller Input Throttle and Controller Motor Power Output.

Data is stored directly in the controller and may be accessed once the run is over using the Castle Link USB adapter (sold separately) and Castle Link software (available free at castlecreations.com). The Max Log Size is 21,504 bytes, everything takes one byte except for motor rpm which takes two.

Logging 'Battery Current' at 1 sample / second - 358 minutes of logging time (almost 6 hrs)
Logging 'Motor RPM' at only 1 sample / second - 179 minutes of logging time
Logging everything at only 1 sample / second - 44 minutes of logging time
Logging everything at 10 samples / second - 4 minutes and 28 seconds

Specifications Ice Lite HV60:
Dimensions:2.6" (66mm) x 1.3" (33mm) x .8" (20.6mm)
Max Input Voltage 50V up to 12S Lipo, 14S A123, 36 cells Nicad or NiMH.
Max Continuous 60 Amps
Brake yes, on/off
Reversible yes - change any two wires
Low Voltage Cut-off, auto lipo or nimh/nicd
Weight (whithout wires) 2 oz. (56.7g)
Universal connector
BEC: Switch rate regulator, 5 amp max adjustable from 5 to 7v in .1v increments.

Castle Link Compatible

Castle Creations Warranty Info.

DISCONTINUED BY CASTLE CREATIONS, WHILE SUPPLIES LAST

Castle Quick Connect does just that. It detects the presence of a Castle Link adapter on the free lead and switches the controller's signal line from the RX to the Castle Link. Makes connecting your Castle Field Link or Castle Link a simple plug in afair with no removal of any of your gear from the model. Easy as that.

Helis: CC CapPack is highly recommended for all 500 class and larger heli applications where Y harnesses and long wires can bleed voltage and hard collective pulls can strain even the most powerful batteries.

Cars/Trucks: With their high torque requirements - going from 0 to 100% throttle isn't easy on controllers or batteries - RC cars and trucks put enormous loads on brushless power systems. Use CC CapPack to help your system power through the abuse.

Aircraft: Larger electric power systems lead to larger electric powered aircraft, and sometimes the distance between the battery pack and the ESC grows beyond the length of the wires installed on the components. Adding wire also adds inductance, which can increase the ripple voltage in a system. CC CapPack essentially negates the ripple caused by the addition of up to 8 inches of length to the battery wires. CC CapPack is designed for quick and easy installation. Users simply cut the soft silicone insulation on the battery wires - do this as close to the ESC as possible - and place the exposed wires in the channels on CC CapPack's posts. Check for proper polarity and then solder the wires to the posts. Use the included heat shrink to finish it off for a professional looking install. Note: All Castle controllers with data logging capabilities can report the ripple voltage they encounter during use. Ripple voltage peaks should always be less than 10% of the total pack voltage; the smaller the ripple voltage the better. If an application exhibits more than 10% ripple voltage under peak loads, the user should consider using higher discharge (C Rating) batteries, shorter wires, higher current connectors, better gearing or a smaller load. Multiple CapPacks may be used in an application. They should all be installed as close to the ESC as possible.

Product #: 011-0002-02

TEMPORARILY OUT OF STOCK, SPECIAL ORDER LEAD TIME 4-8 WEEKS

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect complement to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 22A model comes with a 5.0 volt switching type BEC rated for 2 amps of current.

The Cobra 22A ESC comes with a set of 3.5mm female bullet connectors already installed. These connectors match up with the ones provided on the Cobra Brushless motors as well as most other brands of brushless motors on the market today.

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 22 Amp ESC Specifications

Weight (Without Connectors): 24.2 grams (.85 oz)

Max Continuous Current: 22 Amps

Burst Current rating (15s): 28 Amps

Operating Voltage Range: 6 to 12 Volts

Number of Li-Po cells: 2 to 3 cells

Number of Ni-XX cells: 6 to 10 cells

Number of Li-Fe cells: 2 to 3 cells

Switching BEC Output: 2 amps @ 5. Volts

ESC Size (Inc. Caps, in mm): 44 x 24 x 10

ESC Size (Inc. Caps, in inches): 1.73 x 0.94 x 0.39

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. The 11A and 22A models come with a 5.0 volt linear BEC rated for 2 amps of current.

Since the Cobra 11A ESC is typically used in smaller 2-cell powered indoor aircraft, where most users solder the motor directly to the ESC to save weight, no bullet connectors are provided on the motor output leads. The leads are provided pre-tinned ready to solder.

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for LiFe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low ? Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 11 Amp ESC Specifications

Weight (Without Connectors): 9.9 grams (0.35 oz)

Max Continuous Current: 11 Amps

Burst Current rating (15s) 14 Amps

Operating Voltage Range 6 to 12 Volts

Number of Li-Po cells 2 to 3 cells

Number of Ni-XX cells 6 to 10 cells

Number of Li-Fe cells 2 to 3 cells

Linear BEC Output 2 amps @ 5.0 Volts

ESC Size (Inc. Caps, in mm) 30 x 18 x 10

ESC Size (Inc. Caps, in inches) 1.18 x 0.71 x 0.39

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect complement to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 100A model comes with a 5.5 volt switching BEC rated for 6 amps of current to handle the power needs of the larger digital servos.

Because of the wide range of different motor connectors used on this size speed controller, the Cobra 100A ESC comes without any bullet connectors already installed. The motor leads are pre-tinned and ready to solder on your favorite connectors. 4mm or larger bullet connectors are recommended for this size speed controller.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 100 Amp ESC Specifications:

Weight (Without Connectors): 69.8 grams (2.46 oz)

Max Continuous Current: 100 Amps

Burst Current rating (15s): 125 Amps

Operating Voltage Range: 6 to 26 Volts

Number of Li-Po cells: 2 to 6 cells

Number of Ni-XX cells: 6 to 20 cells

Number of Li-Fe cells: 2 to 7 cells

Switching BEC Output: 6 amps @ 5.5 Volts

ESC Size (Inc. Caps, in mm): 72 x 33 x 14

ESC Size (Inc. Caps, in inches): 2.83 x 1.30 x 0.55

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

NOTE: The Cobra Programming Card is only for use with the Aircraft Versions of Cobra Speed Controllers. These can easily be identified by a green stripe down the center of the label and have part numbers that start with "DL". This program card does not work with the Cobra Multirotor Speed Controllers. These can easily be identified by an all-black label, and part numbers that start with "MR".

The Programming Card is very easy to use, you simply set the six programming jumpers to the desired settings and plug the programming card into the control lead on your ESC. Then, with a motor connected to the ESC, plug in the motor battery and wait a couple seconds. After you hear the confirmation tone, unplug the battery and the programming is complete! To complete the process, unplug the Programming Card for the ESC, and plug the control lead back into the throttle channel on your radio receiver.

With the Cobra ESC Programming Card, you can access all of the programming features available in the speed controller. These features include:

• Battery Type: Three different types of battery chemistry are supported, Li-Po/Li-Ion, Ni-Cad/Ni-MH and Li-Fe/A123. (The default setting is Li-Po/Li-Ion cells)


• Cut-off Voltage Level: For each battery chemistry there are three different Low Voltage cut-off levels available, High, Medium and low. For Li-Po/Li-Ion cells 3.2, 3.0 or 2.8 volts per cell can be selected. For NiCad/Ni-MH cells 0.9, 0.8 or 0.6 volts per cell can be selected. For Li-Fe/A123 cells, 2.8, 2.5 or 2.2 volts per cell can be selected. (The default setting is the Medium setting for each battery chemistry)


• LVC Cut-off Type: When the selected Low Voltage level is reached, the ESC can be set to provide either a Hard Cut-off or a Power Reduction Mode. (The default setting is Power Reduction Mode)


• Brake Level: The Brake Level can be set to one of three levels. Hard Brake, which is used with folding type props, Medium Brake, which is used with normal props or Off, if the user desires to have the prop free-wheel when the ESC is in the idle condition. (The Default setting is Medium Brake level)

• Timing Mode: The ESC Timing can be set to one of three values, Auto to let the ESC determine the best setting for the motor that it is driving, High to get maximum power and performance from high pole count outrunner motors or Low for economic performance and use with low pole count outrunners or inrunner type motors. (The default setting is Auto Timing)


• Motor Acceleration Rate: The Motor Acceleration Rate can be set to one of three values. High is for use in planes where immediate throttle response is desired, such as 3D type aircraft. Medium is for normal sport flying to get smooth throttle transitions when power changes are made. Low is for models with very large props, or motors that are used in gearbox applications to prevent high power pulses that could strip out the gears. (The default setting is Medium Acceleration rate)

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect complement to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 150A model comes with a 5.5 volt switching BEC rated for 6 amps of current to handle the power needs of the larger digital servos.

Because of the wide range of different motor connectors used on this size speed controller, the Cobra 100A ESC comes without any bullet connectors already installed. The motor leads are pre-tinned and ready to solder on your favorite connectors. 5mm or larger bullet connectors are recommended for this size speed controller.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 150 Amp ESC Specifications:

Weight (Without Connectors): 82.0 grams (2.8 oz)

Max Continuous Current: 150 Amps

Burst Current rating (15s): 188 Amps

Operating Voltage Range: 6 to 26 Volts

Number of Li-Po cells: 2 to 6 cells

Number of Ni-XX cells: 6 to 20 cells

Number of Li-Fe cells: 2 to 7 cells

Switching BEC Output: 6 amps @ 5.5 Volts

ESC Size (Inc. Caps, in mm): 72 x 33 x 18

ESC Size (Inc. Caps, in inches): 2.83 x 1.30 x 0.71

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation. The perfect complement to a Cobra Brushless motor!

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect compliment to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 40A model comes with a 5.5 volt switching BEC rated for 6 amps of current to handle the power needs of the larger digital servos.

The Cobra 40A ESC comes with a set of 3.5mm female bullet connectors already installed. These connectors match up with the ones provided on the Cobra Brushless motors as well as most other brands of brushless motors on the market today.

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 40 Amp ESC Specifications

Weight (Without Connectors): 48.4 grams (1.71 oz)

Max Continuous Current: 40 Amps

Burst Current rating (15s): 50 Amps

Operating Voltage Range: 6 to 26 Volts

Number of Li-Po cells: 2 to 6 cells

Number of Ni-XX cells: 6 to 20 cells

Number of Li-Fe cells: 2 to 7 cells

Switching BEC Output: 6 amps @ 5.5 Volts

ESC Size (Inc. Caps, in mm): 64 x 26 x 13

ESC Size (Inc. Caps, in inches): 2.52 x 1.02 x 0.51

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect complement to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 33A model comes with a 5.5 volt switching type BEC rated for 3 amps of current.

The Cobra 33A ESC comes with a set of 3.5mm female bullet connectors already installed. These connectors match up with the ones provided on the Cobra Brushless motors as well as most other brands of brushless motors on the market today.

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 33 Amp ESC Specifications

Weight (Without Connectors): 37.1 grams (1.31 oz)

Max Continuous Current: 33 Amps

Burst Current rating (15s): 41 Amps

Operating Voltage Range: 6 to 17 Volts

Number of Li-Po cells: 2 to 4 cells

Number of Ni-XX cells: 6 to 12 cells

Number of Li-Fe cells: 2 to 4 cells

Switching BEC Output: 3 amps @ 5.5 Volts

ESC Size (Inc. Caps, in mm): 56 x 25 x 10

ESC Size (Inc. Caps, in inches): 2.20 x 0.98 x 0.39

Cobra Speed Controllers are designed with a relentless pursuit of exceptional product quality. These speed controllers are the perfect complement to a Cobra Brushless motor, and they will also work with virtually any other brushless motor on the market as well. Cobra Speed Controllers are built from the best components available to provide the user with long life and trouble-free operation.

Cobra Speed Controllers are simple to program, and in most cases, they can be used right out of the package. Three of the Speed Controller parameters can be set without a programming card: Brake Mode, Battery Type, and Timing mode. The remaining parameters can be set with the optional ESC Programming Card, which is available separately.

All of the Cobra Speed Controllers come with an internal BEC circuit to power your radio receiver and servos. This 60A model comes with a 5.5 volt switching BEC rated for 6 amps of current to handle the power needs of the larger digital servos.

The Cobra 60A ESC comes with a set of 3.5mm female bullet connectors already installed. These connectors match up with the ones provided on the Cobra Brushless motors as well as most other brands of brushless motors on the market today.

Note: The Cobra speed controllers do NOT ship with the programming card. This part must be purchased separately. The same programming card is used for the entire series of Cobra speed controllers so only one programming card is needed for all of your Cobra speed controllers.

Cobra Speed Controller Features

• Easy Set-up and Operation
• Basic Programming available through Throttle Stick
• Throttle Range automatically detected and set for smooth, linear throttle response
• Three different types of Low Voltage Cut-off available for Li-Po, Ni-XX or LiFe batteries
• Three different LVC levels for each cell type: 3.2, 3.0 or 2.8 Volts/cell for Li-Po batteries, 0.9, 0.8 or 0.6 Volts/cell for Ni-XX batteries and 2.8, 2.5 or 2.2 Volts/cell for Li-Fe batteries
• LVC type can be set to Hard Cut-off or Power Reduction Mode
• Three different brake levels, Hard, Medium or Off
• Three different timing modes, High, Low and Auto
• Three different Motor Acceleration Rates, High, Medium and Low
• Safe Start-Up: The ESC will not arm until the throttle is in the idle position
• Locked-Rotor Protection: If the motor is blocked so the prop cannot rotate, the ESC will automatically shut down to prevent damage
• PWM Frequency is set to 8KHz for best operation on a wide range of motors
• Over Temp Protection: Shuts down the ESC output if temperature exceeds 230F (110C)
• Auto Power Cut-off: If the throttle signal is lost for more than 3 seconds, the throttle will reduce to idle to prevent fly-aways.

Cobra 60 Amp ESC Specifications

Weight (Without Connectors): 60.1 grams (2.12 oz)

Max Continuous Current: 60 Amps

Burst Current rating (15s): 75 Amps

Operating Voltage Range: 6 to 26 Volts

Number of Li-Po cells: 2 to 6 cells

Number of Ni-XX cells: 6 to 20 cells

Number of Li-Fe cells: 2 to 7 cells

Switching BEC Output: 6 amps @ 5.5 Volts

ESC Size (Inc. Caps, in mm): 67 x 33 x 14

ESC Size (Inc. Caps, in inches): 2.64 x 1.30 x 0.55
